8006 Aluminium Coil Strip
8006 Aluminum Coil Manufacturers / Aluminum Coil Stock Colors in China
Pure aluminium / aluminum is quite soft, therefore to make it strong, the metal is from time to time alloyed or cold worked. It is reported that most of the aluminium / aluminum that enters the global market has been alloyed with at least one other element.
Aluminium / aluminum 8000 series are alloyed with a variety of elements. Aluminium / aluminum 8006 alloy is a wrought alloy. It possesses good corrosion resistance and high strength.
Chemical Properties - 8006 Aluminium Coil Strip
| Alloy Designation | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Ga | V | Remarks | Others |
Aluminium min |
||
| Numerical | Chemical Sympols | Each | Total | |||||||||||||
|
EN AW -8006 |
EN AW- AI |
0.4 | 1.2-2.0 | 0.3 | 0.3-1.0 | 0.10 | - | - | 0.10 | - | - | - | - | 0.05 | 0.15 | Remainder |
Physical Properties - 8006 Aluminium Coil Strip
The physical properties of aluminium / aluminum 8006 alloy are outlined in the following table.
| Properties | Metric | Imperial |
| Density | 2.74 g/cm鲁 | 0.098 lb/in鲁 |
Mechanical Properties - 8006 Aluminium Coil Strip
The mechanical properties of aluminium / aluminum 8006 alloy are tabulated below.
| Properties | Metric | Imperial |
| Elastic modulus | 70 MPa | 10152 psi |
Thermal Properties - 8006 Aluminium Coil Strip
The thermal properties of aluminium / aluminum 8006 alloy are tabulated below.
| Properties | Metric | Imperial |
| Thermal conductivity | 190-210 W/mK | 1317- 1456 BTU in/hr.ft².°F |
Fabrication - 8006 Aluminium Coil Strip
Aluminium / aluminum 8006 alloy can be welded and formed easily. Adhesive bonding is also possible. Welding can be performed using the techniques such as TIG, ultrasonic, and laser.
